Moderately low 19mm profile height and wide width, balances the benefits of radial compliance with high lateral stiffness and predictable handling
Radial Compliance improves traction over bumps and chatter, while reducing negative feedback to the rider. Performance and comfort are improved
5mm inner width is extremely versatile, fitting tires from 2.0” to 2.6”, and even allowing + size tire use without negative squaring off of tire profiles
Bead Bite tubeless hooks enhance tubeless performance and tire security, even at lower pressures
RECOMMENDED FOR: ASTM 5, All mountain, trail, enduro, free ride, DH, E-Bike
RIDER TYPE: HEAVY TO LIGHT RIDER: Heavy to Light Impact

FRONT WHEELS TO PAIR WITH:


SPANK 350	SPANK 359	SPANK 350 VIBROCORE	SPANK 359 VIBROCORE

CLASSIFICATION & INTENDED USE: ASTM 5

ALL MOUNTAIN	TRAIL	ENDURO	FREERIDE
✔	✔	✔	✔
DOWNHILL	GRAVEL	XC	E-BIKE
✔	-	-	*

* Recommended for E-Bike when adapting with SPANK HEX DRIVE steel freehub (available as seperate purchase in HG, XD and Microspline. (See Hex Drive Service Parts)

HUMAN FACTOR

SPANK's recommendations for what body type and ride style this product is suited to.

BODY WEIGHT & RIDE STYLE:	Heavy Rider	Medium Rider	Light Rider
Heavy Impact	✔	✔	✔
Medium Impact	✔	✔	✔
Light impact	✔	✔	✔

RIM SPECIFICATIONS

HOLE COUNT:	28 / 32
INNER WIDTH (mm):	30.5
OUTER WIDTH (mm):	35
PROFILE HEIGHT:	19
TYRE FIT	2.0" to 2.6"

BUILD SPECIFICATIONS

BUILD:	A-Class Handbuilt
HUB:	SPANK HEX J-TYPE
SPOKES:	J-Hook, tripple butted 2.2/1.8/2.0
NIPPLES:	Brass external
LACING:	3 cross lacing
VALVE:	F/V Presta
TUBELESS:	Tubeless taped & valved

HUB SPECIFICATIONS:

ENGAGEMENT:	HEX DRIVE 102T / 3.5° / 6 Pawl
HOLE COUNT:	28H Straightpull / 32H J-Hook
DISC MOUNT:	6-bolt
MATERIAL:	CNC optimized forged alloy hub body, alloy axle, alloy freehub body

VARIANT SPECS


	HUB	HUB SPACING	BOOST	FREEHUB	HOLE COUNT	ADAPTER INCL.	WEIGHT	ERD	ETRTO	SPOKE LENGTH	SPOKE LENGTH
27.5"	HEX J TYPE	12x148	BOOST	HG	32H	-	1149g	560++	584x30.5	R-270	L-273
	HEX J TYPE	12x148	BOOST	XD	32H	-	1141g	560++	584x30.5	R-270	L-273
	HEX J TYPE	12x148	BOOST	Microspline	32H	-	1077g	560++	584x30.5	R-270	L-273
	HEX J TYPE	12x148	BOOST	HG-E	32H	-	1162g	560++	584x30.5	R-270	L-273
	HEX J TYPE	12x148	BOOST	XD-E	32H	-	1141g	560++	584x30.5	R-270	L-273
	HEX J TYPE	12x148	BOOST	MS-E	32H	-	1147g	560++	584x30.5	R-270	L-273
	HEX J TYPE	12x150	-	HG	32H	12x157	1150g	560++	584x30.5	R-270	L-273
	HEX J TYPE	12x150	-	XD	32H	12x157	1142g	560++	584x30.5	R-270	L-273
	HEX J TYPE	12x150	-	Microspline	32H	12x157	1078g	560++	584x30.5	R-270	L-273
	STRAIGHTPULL	12x148	BOOST	HG	28H	-	1014g	560++	584x30.5	R-284	L-285
	STRAIGHTPULL	12x148	BOOST	XD	28H	-	1007g	560++	584x30.5	R-284	L-285
	STRAIGHTPULL	12x148	BOOST	Microspline	28H	-	1018g	560++	584x30.5	R-284	L-285

29"	HEX J TYPE	12x148	BOOST	HG	32H	-	1197g	598++	622x30.5	R-289	L-292
	HEX J TYPE	12x148	BOOST	XD	32H	-	1189g	598++	622x30.5	R-289	L-292
	HEX J TYPE	12x148	BOOST	Microspline	32H	-	1121g	598++	622x30.5	R-289	L-292
	HEX J TYPE	12x148	BOOST	HG-E	32H	-	1206g	598++	622x30.5	R-289	L-292
	HEX J TYPE	12x148	BOOST	XD-E	32H	-	1194g	598++	622x30.5	R-289	L-292
	HEX J TYPE	12x148	BOOST	MS-E	32H	-	1191g	598++	622x30.5	R-289	L-292
	HEX J TYPE	12x150	-	HG	32H	12x157	1198g	598++	622x30.5	R-289	L-292
	HEX J TYPE	12x150	-	XD	32H	12x157	1190g	598++	622x30.5	R-289	L-292
	HEX J TYPE	12x150	-	Microspline	32H	12x157	1122g	598++	622x30.5	R-289	L-292
	STRAIGHTPULL	12x148	BOOST	HG	28H	-	1058g	598++	622x30.5	R-303	L-304
	STRAIGHTPULL	12x148	BOOST	XD	28H	-	1050g	598++	622x30.5	R-303	L-304
	STRAIGHTPULL	12x148	BOOST	Microspline	28H	-	1062g	598++	622x30.5	R-303	L-304

Use the table below to determine compatible adapters & service parts, or visit the service parts collection by clicking here.

ADAPTERS COMPATIBLE WITH SPANK HEX J-TYPE REAR HUBS

Boost R148:	HEX Rear Hub QRx135/141 Adapter
R150/157:	N/A
R135/142:	HEX Rear Hub QRx135/141 Adapter
	HEX Rear Hub 10x135 Adapter

SERVICE KITS COMPATIBLE WITH SPANK HEX J-TYPE REAR HUBS

HEX Rear HG/HGR Hub Replacement Bearing Kit

HEX Rear XD/XDR Hub Replacement Bearing Kit

HEX Boost Rear Hub Alloy Axle Shaft

HEX Rear Hub 135/142mm Alloy Axle Shaft

HEX Rear Hub 150/157mm Alloy Axle Shaft

HEX Rear Hub HG Alloy Anti-Bite Freehub

HEX Rear Hub XD Alloy Freehub

ADAPTERS COMPATIBLE WITH SPANK HEX STRAIGHTPULL REAR HUBS

Boost R148:	Rear Hub QRx135/141 Adapter

SERVICE KITS COMPATIBLE WITH SPANK HEX STRAIGHTPULL REAR HUBS

HEX Rear HG/HGR Hub Replacement Bearing Kit

HEX Rear XD/XDR Hub Replacement Bearing Kit

HEX Boost Rear Hub Alloy Axle Shaft

HEX Rear Hub HG Alloy Anti-Bite Freehub

HEX Rear Hub XD Alloy Freehub
